Stock Bore Bushings
Stock Bore Bushings Type Pulleys
Range of product:
DIN:(1008/1180/1210/1215/1310/1610/1615/2012/2517/2525/3020/3030/3535/4040/4545/5050)
Inch size product (Apply to DIN market)
Product Details
Series Type | SizeRange | |
DIN | 1008 | 10-25 |
1180 | 10-28 | |
1210 | 11-32 | |
1215 | 11-32 | |
1310 | 24-35 | |
1610 | 14-42 | |
1615 | 14-42 | |
2012 | 18-50 | |
2517 | 20-60 | |
2525 | 20-60 | |
3020 | 25-75 | |
3030 | 25-75 | |
3535 | 35-90 | |
4040 | 25-75 | |
4545 | 55-110 | |
5050 | 60-125 |
DIN Standard:
